CXH2-4P port light

Visible distance 1n. m
Horizontal arc 112.5 °
Light bulb power 12~24V 5W
Protection level IP56
Cable outer diameter Φ 10- Φ 12
Yan Se Hong
Weight 0.53kg
Light source LED

Scope of application for CXH2-4P port light

Suitable for night navigation light signal communication on ships below 12 meters.
Product Features
The shell is made of high-strength engineering plastic PA+GF material injection molded, the transparent cover is made of PC injection molded, and the light shielding plate is made of high-quality copper alloy compression molded;
The signal lights have an overall sealed structure and are waterproof when used in harsh environments;
Select LED light sources that comply with ship regulations for signal lights.
The signal lights can work normally within the ambient temperature range of -30 ℃~55 ℃.
Adopt standards
1. Comply with the 1972 International Regulations for Preventing Collisions at Sea and the Classification and Construction Code for Steel Ships;
2. Complies with the international IEC60598-1-2008 standard;
3. Comply with the national standard GB/T3028-1995 Technical Conditions for Ship Electrical Signal Lights.
