Rated power (W)

four hundred

Rated current (A)

ten

Rated voltage (V)

forty-eight

Machine base number (mm)

sixty

Speed (r/min)

three thousand

Rated torque (N · m)

zero point six four

Body length (mm)

ninety-seven point four

Shaft diameter (mm)

fourteen

Integrated encoder

17 bit single loop absolute value encoder

communication method

Modbus

control mode

Capable of multiple position/speed/torque commands/origin reset application modes

Fault detection and protection

It has protection functions such as overcurrent, overvoltage, undervoltage, overload, and over tolerance, and optional output alarm prompts.

Integrated I/O

Three configurable digital input interfaces and one digital output interface.

Usage environment

Installation environment: Try to avoid dust, oil mist, and corrosive gases as much as possible;
Working temperature: 0 ℃~50 ℃;
Storage temperature: -20 ℃ to+60 ℃
Working environment humidity: 20% to 95% RH (non condensing)
