Motor specifications

WM130ST-Z1M11515GYA5-B1

Rated power (W)

one thousand and eight hundred

Rated voltage (V)

two hundred and twenty

Rated current (A)

thirteen point eight

Rated torque (N.m)

eleven point five

Rated speed (r/min)

one thousand and five hundred

Instantaneous maximum current (A)

forty-one point four

Instantaneous maximum torque (N.m)

thirty-four point five

Instantaneous maximum speed (r/min)

three thousand

Reverse electromotive force (V/1000r/min)

fifty-two

Torque coefficient (N.m/A)

zero point eight three

Winding (wire to wire) resistance (Ω)

zero point three five

Inductance (mH)

two point five

Electrical time constant (ms)

seven point one four

Rotor inertia (kg. m2 × 10-4)

twenty-two point six three

Weight (kg)

eleven point three

pole pair

5 pairs of poles

Motor insulation grade

Class F

protection level

IP65

Usage environment

Environmental temperature: -20 ℃~40 ℃ Environmental humidity: Relative humidity<90% (under non frost conditions)
