Motor specifications

WM130ST-Z1M14315HYA5-B1

Rated power (W)

two thousand and two hundred

Rated voltage (V)

three hundred and eighty

Rated current (A)

ten point five

Rated torque (N.m)

fourteen point three

Rated speed (r/min)

one thousand and five hundred

Instantaneous maximum current (A)

twenty-nine point four

Instantaneous maximum torque (N.m)

forty

Instantaneous maximum speed (r/min)

three thousand

Reverse electromotive force (V/1000r/min)

ninety-two

Torque coefficient (N.m/A)

one point three six

Winding (wire to wire) resistance (Ω)

zero point eight five

Inductance (mH)

five point six

Electrical time constant (ms)

six point five eight

Rotor inertia (kg. m2 × 10-4)

twenty-eight point three three

Weight (kg)

twelve point five

pole pair

5 pairs of poles

Motor insulation grade

Class F

protection level

IP65

Usage environment

Environmental temperature: -20 ℃~40 ℃ Environmental humidity: Relative humidity<90% (under non frost conditions)
